Sporlan C-415-S-HH

Sporlan Catch-All® Sealed Liquid Line Filter Dryer with Charcoal Style Core, 5/8 Inch SAE Flared, 41 cu-Inch Desiccant
SKU: 79738
Manufacturer part number: C-415-S-HH
Manufacturer:

Parker Hannifin


Please Sign In to display product price.

Sporlan Catch-All® Liquid Line Filter Dryer, Sealed, R-134a, R-22, R-404A, R-507, R-407C and R-410A, For Use With: All CFC, HCFC and HFC Refrigerants, 5/8 Inch SAE Flared, 8-1/4 Inch Cut-Out Length, 41 cu-Inch Desiccant, 650 psi, 9.35 Inch Overall Length, Steel, 3-1/2 Inch Dia

  • Charcoal style core for wax removal and clean up after a hermetic motor burnout
  • The Catch-All® filter drier will filter out scale, solder particles, carbon, sludge, dirt or any other foreign matter with negligible pressure drop
  • The Catch-All® filter drier is unexcelled in acid removal ability
  • Charcoal style core for wax removal and clean up after a hermetic motor burnout





Standard/Approvals: UL Listed

Products specifications
Attribute nameAttribute value
Connection Type5/8 Inch SAE Flared
Cut Out Length8-1/4 Inch
Desiccant Volume41 cu-Inch
Dimensions3-1/2 Inch Dia
ManufacturerParker Hannifin
MaterialSteel
Overall Length9.35 Inch
Pressure Rating650 psi
Refrigerant TypeR-134a, R-22, R-404A, R-507, R-407C and R-410A
SeriesCatch-All®
Suitable For Use WithAll CFC, HCFC and HFC Refrigerants
TypeSealed
